3M super- lub teeb Carbon fiber ntau boom ncej ua los ntawm Xinbo Composite tsuas yog nyob ib ncig ntawm 550g, nrog tsuas yog 0.7 hli phab ntsa tuab thiab ntau - axial fiber layup ua rau nws nqa mus rau kev thauj mus los.
Product Description
Khoom | Carbon Fiber Boom Ncej |
Khoom siv | Carbon Fiber (Standard Modulus) |
Nto | Polished Matte |
Qauv | UD |
MIN OD | 21.8mm 3 |
MAX OD | 37.7mm ib |
Ntev ntev | 3 M |
Tshooj | 6 |
Daim ntawv cog lus ntev | 0.68 M |
OD Tolerance | ± 0.05 hli |
Qhov hnyav | 550g |
Clamp | Anodized Aluminium Twist Lock |
Lus hais | Txoj kab uas hla & Extended Length tuaj yeem kho tau |
Txheej txheem tsim khoom
Yob qhwv lub raj yog tsim los siv ntau txheej ntawm prepreg carbon fiber cov ntaub ntawv. Feem ntau, txhua txheej yog li 0.13 ~ 0.25 hli tuab uas txhais tau hais tias lub raj nrog phab ntsa tuab ntawm 1.5 hli feem ntau yuav muaj li ntawm 6-12 tus neeg txheej ntawm carbon fiber. Tus naj npawb ntawm cov khaubncaws sab nraud povtseg tso cai rau peb sib txawv cov kev taw qhia ntawm cov fibers thoob plaws hauv lub thickness, tsim kom muaj kev ua tau zoo tshaj plaws raws li ib tus neeg yuav tsum tau muaj.
Qhov zoo | Daim ntawv thov |
Tsis zoo li cov hlau uas muaj cov khoom zoo sib xws hauv txhua qhov kev taw qhia, cov khoom ntawm cov khoom sib xyaw sib txawv, nyob ntawm qhov kev taw qhia ntawm cov fibers hauv txhua txheej. 1. Nplej nplej thiab du nto 2. Lub zog muaj zog, lub teeb yuag 3. Kev tiv thaiv -Corrosion 4. Tsawg Thermal Expansivity 5. Tsawg Fiber Ceev 6. Kev qaug zog zoo 7. Portable & Yooj yim rau kev khiav lag luam | - Aerial Photography - Kev Tshawb Fawb & Kev Ntsuas - Microphone Boom Ncej |
