Filament winding yog txheej txheem tsim khoom uas cov fibers raug mob ntawm lub kaum sab xis ntawm qhov nro. Peb yuav tsim cov kab mob fiber ntau raws li lub zog xav tau ntawm lub raj. Peb filament winding carbon fiber tubes tuaj yeem ua los ntawm cov khoom siv ntuj tsim, polished du nto los yog cov txheej txheej ntshiab.

Product Description

Khoom	Filament Winding Carbon Fiber Tubes
Khoom siv	Standard Modulus / High Modulus (Yeem)
Nto	Polished
Qauv	Ntau Axial Fiber
MIN OD	7.2mm ib
MAX OD	12 3mm
MAX Length	1800 hli
Ua siab ntev	Polished Tubing: ± 0.02mm ~ ± 0.05mm

Lay-Txoj kev taw qhia

Lay-Txoj kev taw qhia	± 45 degree

	Lwm yam Customized Multiple Axial Angles

Txheej txheem tsim khoom

Filament winding txheej txheem muaj ob yam tseem ceeb. Ib qho chaw ruaj khov steel mandrel tig, thaum lub tsheb nqa caj npab taug kev horizontally nce thiab nqis ntawm qhov ntev ntawm mandrel. Raws li lub mandrel tig, cov rovings qhwv ib ncig ntawm nws los tsim ib txheej txheej ntawm mandrel nto. Ua ntej ntsib lub mandrel, cov fibers yog impregnated nyob rau hauv ib tug resin, uas tom qab ntawd solidifies nrog fiber ntau los tsim cov khoom sib xyaw zaum kawg.

Qhov zoo

Daim ntawv thov

Ib qho txiaj ntsig loj ntawm filament winding yog tias nws siv cov fibers txuas ntxiv uas ua rau cov khoom siv zoo heev rau ob qho tib si lub zog thiab nruj.

1. Lub zog muaj zog, siab tawv, lub teeb yuag

2. Kev tiv thaiv -Corrosion

3. Tsawg Thermal Expansivity

4. Zoo Fatigue Resistance

5. Tus nqi tu qis

6. Ntau Axial Angles tuaj yeem tsim kom ncav cuag qhov kev ua tau zoo tshaj plaws.

- Industrial Automation

- Aerospace

- Kev Nyab Xeeb & Kev Tiv Thaiv

- Cov khoom siv ua yeeb yaj kiab thiab TV

- Tsheb thiab maus taus Accessory

- Kev ua si
